Horizontal Injection Moulding Machine (C Series)
The C Series is a range of horizontal plastic injection moulding machines from Pratishna Engineers, built for container making and thin-wall packaging. The series spans 140 to 320 tons across five models, with high injection rates, long clamping strokes and deep daylight openings, so containers, tubs, pails, lids and closures fill fast and eject cleanly.
Pratishna Engineers is one of the top and trusted container injection moulding machine manufacturers in India. Based in Mumbai, the company brings 35+ years of machine-building experience and has supplied 9,000+ machines to 1,000+ customers, offering the C Series for food, dairy, paint, FMCG and industrial packaging, backed by in-house engineering and after-sales support.
Across the range, screw diameters run from 35 to 65 mm, shot weights from 151 to 821 g (PS) and injection rates up to 300 cc/sec, with daylight openings from 750 to 1,125 mm, ejector strokes up to 150 mm and platens from 640 × 570 mm to 910 × 930 mm. Select a model by container size, wall thickness, cavities, mould height and output, since thin walls and deep moulds set the requirement more than part weight.
- Clamping force
- 140 – 320 T
- Models
- 5
- Shot weight
- High
Need Help Selecting a C Series Machine?
Contact Pratishna Engineers to discuss your container or packaging requirements and request C Series specifications, application guidance and a quotation.
C Series Horizontal Injection Moulding Machines by Tonnage
The Pratishna C Series is available in five clamping-force options: 140, 180, 220, 260 and 320 tons, most with two or three screw options. Smaller models suit caps, closures, cups and small tubs in multi-cavity moulds, while larger models suit pails, larger containers and high-cavity thin-wall moulds.
- 140 TonC-140Screw optionsØ35Shot weight151 gView specs →
- 180 TonC-180Screw optionsØ40 · Ø45Shot weight249 – 315 gView specs →
- 220 TonC-220Screw optionsØ45 · Ø50 · Ø55Shot weight343 – 513 gView specs →
- 260 TonC-260Screw optionsØ55 · Ø60Shot weight513 – 610 gView specs →
- 320 TonC-320Screw optionsØ60 · Ø65Shot weight699 – 821 gView specs →
C Series specifications by model
Screw diameter and shot weight are shown for each injection unit option on that model. The C-220 offers three.
Locking unit | C-140 | C-180 | C-220 | C-260 | C-320 | |
|---|---|---|---|---|---|---|
| Specification | Unit | |||||
| Mould clamping force | Tons | 125 | 180 | 200 | 250 | 320 |
| Space between tie bars (H × V) | mm | 405 × 340 | 480 × 424 | 540 × 517 | 580 × 497 | 600 × 594 |
Injection unit | C-140 | C-180 | C-220 | C-260 | C-320 | |
|---|---|---|---|---|---|---|
| Specification | Unit | |||||
| Screw diameter | mm | 35 | 40 / 45 | 45 / 50 / 55 | 55 / 60 | 60 / 65 |
| Max. shot weight (PS) | g | 151 | 249 / 315 | 343 / 424 / 513 | 513 / 610 | 699 / 821 |
General | C-140 | C-180 | C-220 | C-260 | C-320 | |
|---|---|---|---|---|---|---|
| Specification | Unit | |||||
| Total connected load | kW | 19.1 | 34.5 | 43.6 | 52.7 | 58 |
Looking for the Right Injection Moulding Machine?
Tell us your production requirements and get a suitable Pratishna machine recommendation.
Why Choose Pratishna Engineers?
- Application-Based Machine Selection
- In-House Engineering & Manufacturing
- Multiple Machine Series
- Production-Focused Solutions
- End-to-End Technical Support
- Industry-Specific Solutions
- Machine Lifecycle Support
About Pratishna Engineers: Injection Moulding Machine Manufacturer in India
Pratishna Engineers Limited is a Mumbai-based manufacturer of plastic injection moulding machines in India, with 35+ years of machine-building experience. The company has in-house capabilities for machine design, manufacturing, assembly, testing and service, providing injection moulding solutions for different plastic processing requirements.
Pratishna Engineers manufactures horizontal, PET, special purpose, two-platen (PHM Series), hybrid and vertical injection moulding machines. Machines are configured according to the plastic component, mould, material, production volume and application requirements.
With 9,000+ machines supplied to 1,000+ customers, Pratishna Engineers serves manufacturers across automotive, packaging, electrical and electronics, medical, consumer products, agriculture and industrial applications in India and international markets.
- 9,000+
- Machines Supplied
- 1,000+
- Customers
- 35+
- Years of Engineering
- 25,000sq. ft.
- Manufacturing Facility
More About Horizontal Injection Moulding Machines
What Is a Horizontal Injection Moulding Machine?
A horizontal injection moulding machine is a type of injection moulding equipment in which the injection unit and mould are arranged along a horizontal axis.
Read More: What Is a Horizontal Injection Moulding Machine?
How Does a Horizontal Injection Moulding Machine Work?
In a horizontal machine, the injection unit and clamping unit sit along a horizontal axis. The mould mounts vertically on the platens, and finished parts are ejected and drop clear of the mould.
Read More: How Does a Horizontal Injection Moulding Machine Work?
Horizontal vs Vertical Injection Moulding Machines: Key Differences
The difference is the axis on which the clamp acts, and it changes what each machine is good at.
Read More: Horizontal vs Vertical Injection Moulding Machines: Key Differences
Important Specifications to Consider Before Buying a Horizontal Injection Moulding Machine
Choosing a horizontal injection moulding machine should be based on the component and moulding process rather than machine tonnage alone.
Read More: Important Specifications to Consider Before Buying a Horizontal Injection Moulding Machine
Applications of Horizontal Injection Moulding Machines
Horizontal machines cover the large majority of injection-moulded components, including household items, packaging, electrical parts, automotive components, agricultural and irrigation parts and general engineering components.
Read More: Applications of Horizontal Injection Moulding Machines
Injection Moulding Machine Buyer Resources
Download practical resources to help you select, size and specify the right machine.
- Image to be provided by client
C Series Catalogue
The C Series container making range from 140 to 320 tons, with model and screw options, main features and packaging applications.
Download PDFPDF · 2.9 MB
C Series Specification Sheet
Actual Pratishna C Series data for every model and screw option: screw diameter, shot weight, injection pressure and rate, clamping force and stroke, mould thickness, daylight, tie-bar space, platen size, ejector, motor power, weight and floor space.
Injection Moulding Machine Selection Guide
A step-by-step guide covering the key inputs needed to select the right machine: product weight, projected area, number of cavities, plastic material, required clamping force, shot / injection capacity, mould dimensions, production quantity, cycle time and automation requirement.
Download PDFPDF · 265 KB
FAQs / Buyer Questions
The answers our engineers give most often, before a C Series specification is agreed.
What Is the Pratishna C Series Horizontal Injection Moulding Machine?
The C Series is Pratishna’s range of horizontal injection moulding machines for container making, available from 140 to 320 tons across five models.What Makes a Machine Suitable for Container Making?
Thin-wall containers need a high injection rate and pressure to fill before the melt freezes, and deep moulds need a long clamping stroke, large daylight and a long ejector stroke. The C Series reaches injection rates up to 300 cc/sec, daylight up to 1,125 mm and ejector strokes up to 150 mm.Which Products Are Made on C Series Machines?
Food and dairy containers, IML tubs, ice cream containers, cups, lids, paint pails and lids, square tubs, caps and closures, and other thin-wall packaging.Which C Series Model Is Suitable for My Container?
The model depends on container size, wall thickness, projected area, number of cavities, mould height and output. Share your container drawing and mould details and Pratishna Engineers will recommend a model.
Can C Series Machines Run Multi-Cavity Hot Runner Moulds?
Yes. Caps, closures and small containers are usually run in multi-cavity hot runner moulds. The model is chosen for the total projected area, shot weight and the platen and tie-bar space the mould needs.What Plastic Materials Can the C Series Process?
Depending on the machine configuration, the C Series can process thermoplastics such as PP, PE, ABS, PS, nylon, PC, POM and other engineering plastics. Material-specific screw and barrel requirements should be evaluated before selection. Most containers use PP copolymer, high-flow PP, HDPE or LDPE.What Is the Difference Between the C, E and H Series?
The C Series (140 to 320 tons) is built for container making and thin-wall packaging. The E Series (75 to 180 tons) suits small and medium parts, and the H Series (120 to 350 tons) is built for household articles and larger parts.Does Pratishna Provide Installation and Support for C Series Machines?
Yes. Pratishna Engineers provides installation, commissioning, operator training and after-sales technical support, along with spare parts, as part of its machine lifecycle services.
Related Blogs, Guides & Articles
Caps and Closures Moulding on 140 to 320 Ton Machines
Caps and closures moulding on 140 to 320 t machines: mould size vs clamp, closure design, tethered caps, cooling and food rules, with a 48-cavity check.
Container Making Machines: Injection Rate, Stroke and Tonnage
How to size a container making machine: injection rate for thin walls, opening stroke for deep parts and clamp force, with a worked tub example.
Deep Container Moulds: Daylight, Ejector Stroke and Cycle Time
Deep container moulds: how much daylight and opening stroke you need, how far to eject, and where cycle time goes, with a worked pail cycle check.
Thin-Wall Container Moulding on 140 to 320 Ton Machines
Thin-wall container moulding on 140 to 320 t machines: fill speed, pressure, clamp factor, barrel size, cooling and FSSAI rules, with a worked screw check.
